ADS Race Multi-Bypass Ring (MBR) Coil Over Remote Reservoir - 3.0x14" Travel - Each Shock

ADS is redefining high-performance suspension with their groundbreaking Multi Bypass Ring (MBR) Coil over Shocks — 3.0" x 14" travel per shock — engineered to raise the bar in adjustability, control, and durability.

MBR TECHNOLOGY (MULTI-STAGE BYPASS RING)

• True multi-stage bypass system with independently adjustable zones

• Positive stop helix system for precise and repeatable tuning

• Delivers high flow performance comparable to 7-tube external bypasses on 16" stroke shocks

• Internal free-bleed ports allow tuners to fine-tune the damping curve for specific vehicle needs

• Integrated top-out zone provides both mechanical and hydraulic damping to prevent damage during full extension

• Limit straps are recommended for racing and extreme-duty use

4-WAY ADJUSTABLE REMOTE RESERVOIR

• Independent high- and low-speed adjusters for both compression and rebound

• Dual-hose design enables a true recirculating fluid path

• Internal diverters ensure full-body fluid flow for enhanced cooling efficiency

BUILT FOR EXTREME PERFORMANCE

• Vacuum-bled and filled with high-performance synthetic fluid to reduce fade and extend service life

• Oversized 2.5" reservoirs boost fluid capacity for superior thermal management

• High-temp seals prevent blow-by and maintain consistent damping under extreme temperatures

• Threaded end caps safeguard against external contamination

• Advanced 3-stage urethane seal package provides unmatched sealing in all climates—from snowy trails to desert heat

SPECIFICATIONS

•  Brand: ADS

• Part Number: 300-MBR14-000

•  UPC: 090127839294

• Category: Suspension

•  Sub-Category: Shocks and Struts

• Product Type: Internal Bypass Shock

• Part Type: Suspension Shock Absorber

• Stroke Length: 14 in

• Compressed Length: 23.99 in

• Extended Length: 37.99 in

• Mounting Width / Bolt Size: 1.5" x 0.500"

• Emission Code: 6

• California Proposition 65: No

• Quantity: Sold individually
